1500 Reel to sheet litho-laminator with stacker By Yiwu Innovo Printing Machinery Co., Ltd.,

1500 Reel to sheet litho-laminator with stacker

Precio FOB

Obtener el precio más reciente

( Negotiable )

1 Set Minimum Order

País:

China

N º de Modelo:

008

Precio FOB:

( Negotiable )(Negociable) Obtener el precio más reciente

Lugar de origen:

china shanghai

Precio de pedido mínimo:

Cantidad de pedido mínimo:

1 Set

Detalle de embalaje:

wooden package

El tiempo de entrega:

45 days after payment

Capacidad de suministro:

20 Set per Month

Tipo de pago:

L/C, Western Union, Money Gram

Grupo de productos :

litho laminator

Especificaciones del producto

Brand Name: Yiwu Innovo Printing Machinery Co., Ltd.
Packaging Material: Paper
Automatic Grade: Automatic
Application: Machinery & Hardware
Condition: New
Packaging Type: Cartons
Driven Type: Electric

Descripción del producto

Hydraulic mill roll stand:

The maximum paper roll diameter: 1500mm
The maximum paper roll weight: 4500kg
Strong design, full hydraulic driver, ensure stable and reliable work
Use the expansion chip to prevent damage to the paper core
Pneumatic multi -point brake control paper roll tension is constant
Multi -point brakes

Automatic splicer machine:

Maximum paper join width: 1450mm/1650mm
Maximum rolling paper diameter: 1500mm
Minimum resistance: 3n/mm
Scope of tension control: 10-100kgf
Electrical control part, main control PLC control, low failure rate, high machine stability

Corrugated traction system

Swing roller can automatically adjust the tension of corrugated
The gap between the pressure roller is free to adjust, suitable for different types of corrugated
Driven from the frequency reduction reducer.
Point control the conveying corrugated for convenience to wear paper.

Underground or ground conveyor

It is convenient for the paper head to transport when wearing paper
There are belt running partial devices on both sides of the dynamic roller.

Bottom sheet aligner system

Adopt a high -precision aligner system to ensure the fit accuracy

Corrugated traction glue machine

Use a circulating glue system to reduce glue loss, stabilize glue adhesion effect
Can use white glue or starch glue
Gluing roller: stainless steel material, dynamic balance correction, surface grinding treatment

7. Servo sheeter
Synchronous servo cutting, color marking detection, positioning and tailoring
Imported servo system
Imported spiral blade

Automatic flute laminator

The highest line speed 200m/min
High speed laminating, corrugated does not require secondary positioning
Servo positioning to

País:	China
N º de Modelo:	008
Precio FOB:	( Negotiable ) (Negociable) Obtener el precio más reciente
Lugar de origen:	china shanghai
Precio de pedido mínimo:	-
Cantidad de pedido mínimo:	1 Set
Detalle de embalaje:	wooden package
El tiempo de entrega:	45 days after payment
Capacidad de suministro:	20 Set per Month
Tipo de pago:	L/C, Western Union, Money Gram
Grupo de productos :	litho laminator
